latest testing Pickup presentation
This is a truck electric pickup truck, which can be used as a daily passenger transport and cargo transport vehicle. It can be customized according to demand. It can be used for both oil and electricity. The powerful power motor can travel and pull goods. It is equipped with LED headlights and reversing images as standard. The vacuum tire can adapt to various terrain and road conditions. Double row and four seats can carry people and goods, and the rear bucket is fully enclosed to ensure the safety of goods. We have been committed to the R & D, manufacturing and sales of electric vehicles for many years. We look forward to becoming your long-term partner in China.
Product parameters
Size
|
3400*1350*1700mm
|
Carriage size
|
1500*1350*300mm
|
Max speed
|
40km/h
|
Min steering radius
|
≤5m
|
Max climbing ability(full)
|
20%
|
Braking Distance
|
≤7m
|
Working Range
|
80-200m
|
Motor
|
60V 3KW AC Motor, 72V 4KW or 5KW AC motor is optional
|
Min Ground Clearance
|
≥150mm
|
Loading Capacity(kg)
|
500kg
|
Battery
|
60V or 72V lead acid battery or lithium battery
|
Charger
|
Build-in smart car charger
|
Controller
|
Imported in-power controller
|
Driven Method
|
RR
|
Braking Method
|
Four wheel Disc Brake
|
Body Structure
|
Intelligent loading body
|
Front Axle loading Cap.
|
500kg
|
Rear axle loading capacity
|
800kg
|
Climbing Ability
|
20-30%
|
Tyre
|
145/70R12 Pneumatic tyres
|
Steering system
|
Gear chain
|
Lights and signal
|
LED front lamp, turning light, rear lights, braking light,horn, automatic key control, skylight
|
Seat
|
leather+PU
|
instrument
|
Instrument panel,RDP button
|
Product features and applications
In addition to environmental protection and energy saving, this heavy-duty electric pickup truck is equipped with a 3500 watt motor and a 72V battery to give full play to the climbing and loading functions of the vehicle, with a range of about 100 kilometers. Double row seats and covered body provide good riding and storage space. It is suitable for family transportation or simple goods transportation vehicles.
Product details
Company size
Delivery of shipments and services
FAQ
Q1 How to place an order?
1) Contact customer service to confirm the freight and product model, configuration, quantity and other details (you can also arrange your own freight forwarder);
2) We provide you with a proforma invoice containing all product details in accordance with your final decision;
3) You need to arrange 30% payment to our bank account, then we will prepare the product to start production (the cycle is generally about 10 days, can be specially configured for your order quantity delivery);
4) After the product is completed, we will pay the remaining payment and arrange delivery by our forwarder (or we can provide relevant information and arrange forwarder transportation by ourselves).
5) Upon completion of this process, customer service will track the location of the product and notify you of its imminent arrival and arrival so that you can quickly prepare for customs clearance and other related issues.
Q2 What does your FOB reference price include?
A: FOB includes costs only. If you do not have your own freight forwarder, please provide us with the port country/region near you and we will quote cif including freight.
Q3 What is your warranty service?
A: We offer a one-year warranty for the motors, batteries and controllers.
Q4 Why can't I use Courier service and order by myself?
A: Packaged, the product is bulky and contains a large number of batteries. It can be transported by rail but the cost is too high (the appearance of the product may wear out).
Q5 What if I still insist on home delivery?
A: Please provide your address and then we can check the details and arrange.
Q6 What is your production/delivery time for ?
A: The production/delivery time will be controlled within 30 days (generally 10 days can be shipped, simple configuration is 2-3 days).
Q7 Do you test everything before shipping?
A: Yes, we have passed 100% testing before shipment (basic equipment testing also includes roads, hill climbing, rain, water crossing roads, etc.).
Q8 Do you support sample shipment?
A: Yes, we support shipping samples to the port.
Q9 how to guarantee my order after placing order?
A: We will track your order and provide production videos throughout the process. After delivery, the location of the item will also be tracked and provided to you until you receive the item. There will also be a dedicated customer service to receive your follow-up feedback.
Q10 Can you produce Q10 according to the sample?
A: Yes, we can produce according to your samples or technical drawings. We can build molds and fixtures.
Q11 What are your payment terms?
Answer: 30% as deposit, and pay 70% balance before delivery. We will show you photos and videos of the products and packaging before
