14-seat Enclosed Electric Tour Bus
As the professional manufacturer, we would like to provide you 14-seat Enclosed Electric Tour Bus.LCD instrument display (including voltage, current, speed, mileage, lighting, frontand rear direction and other signals, reversing image)
Send Inquiry
Product Description
| Make and model | 14-seat enclosed electric tour bus | ||
| Serial number | Composition system | Key accessories | Details of accessory parameters |
| 1 | Electricalsystem | Electronic control | Fully intelligent controller (overtemperature protection circuit) |
| 2 |
|
Battery | 72-volt lead-acid battery (one-year warranty) |
| 3 |
|
Electric machinery | 5 kW Depuda motor, Inbol controller |
| 4 |
|
Charger | Vehicle-mounted intelligent charger |
| 5 |
|
Charging time | 8-10 hours (discharge rate is 90%) |
| 6 | Technicalparameter | Charging input voltage | 220V |
| 7 |
|
Length*width*height | 5220×1600×2080mm |
| 8 |
|
The quality of vehicle equipment | 1070kg |
| 9 |
|
Whole vehicle loading | 1300kg |
| 10 |
|
Front and rearwheelbase | 1350/1350mm |
| 11 |
|
Wheelbase | 2570mm |
| 12 |
|
Minimum groundclearance | 335mm |
| 13 |
|
Brake distance | ≤5m |
| 14 |
|
Rated crew | 14 people |
| 15 |
|
Maximum driving speed | 35km/h (adjustable) |
| 16 |
|
Maximum climbing slope | 10% |
| 17 |
|
Minimum turning radius | 6.5m |
| 18 |
|
Continuing mileage | 100 kilometers |
| 19 | Body system | The seat | Row seats (leather fabric + high rebound PU, beige seats) |
| 20 |
|
Car body | Steel frame + car-grade wrench gold shell molding parts |
| 21 |
|
Appearance | LCD instrument display (including voltage, current, speed, mileage, lighting, frontand rear direction and other signals, reversing image) |
| 22 |
|
Rear-view mirror | Manual external rearview mirror |
| 23 |
|
Front windshield | Car-specific laminated glass is equipped with a wiper |
| 24 |
|
Lighting and signal | LED combination headlight, turn signal, combination rear taillight, brake light, electric horn |
| 25 |
|
Sound | On-board MP3 machine, professional speaker |
| 26 |
|
Switch | Start switch, light and wiper combination switch, in and out gear switch |
| 27 |
|
Door | Not have |
| 28 |
|
Frame | The overall frame of the steel structure optimizes the anti-rust paint treatment, sothat the vehicle can be used in areas with high salt content and high temperature. |
| 29 |
|
Steering wheel | Polyurethane foam steering wheel |
| 30 | Chassis system | Power transmission system | Infinitely variable speed system |
| 31 |
|
Steering system | Gear rack directional machine |
| 32 |
|
Front bridge and suspension | The front suspension is the front bridge McPherson independent suspension, spiralspring + barrel hydraulic shock absorption. |
| 33 |
|
Reand bridge and suspension | The integral rear axle has low noise, large load and strong climbing ability. The rearsuspension is a multi-piece spring steel plate + cylindrical hydraulic shockabsorption. |
| 34 |
|
Brake system | Front disc and rear drum hydraulic brakes, dual-circuit hydraulic brakes, and parkingbrakes are safer and more stable. (Brake power). |
| 35 |
|
Wheel | 12×4.5 reinforced aluminum alloy wheel hub +155R12C weighted vacuum radial tire |
