Pure electric mining electric vehicle

You are welcomed to come to our factory to buy the latest selling, low price, and high-quality Pure electric mining electric vehicle.

Send Inquiry

Product Description

You are welcomed to come to our factory to buy the latest selling, low price, and high-quality Pure electric mining electric vehicle.

Vehicle load	LH-D40(4 tons)	LH-D30(3 tons)	LH-D20(2 tons)	LH-D10(1 ton)
Overall dimension	370014001550mm	340013001400mm	320013001300mm	300012001280mm
Case size	23001400550mm	20001300400mm	18001300400mm	16001200400mm
gradient	S18%	S18%	S18%	s15%
Container thickness	5mm	5mm	3mm	3mm
Operating voltege	72V o	72V	72V	60V
Marlmum speed	≤15Km/h	S15Km/h	≤15Km/h	s15Km/h
Self-diseharging method	5 tons thick three cection dump top	5 tons dump oil top	3 tons dump oil top	2 tons dump oil top
Damping tyPe	Double outer spring coars e shock absorber for mine	Double outer spring coarse shock absorber	Additional shock sbworption	Spring damping
Motor Power	10KW specia motor	Tai six phase permanent magnet synchromous 8000W	Datai Permanent magnet synchronous 4000W	Brushless 2200W
Rear axle type	Special 130 weighted suspension oll brake rear axle	90 Increase suspension high low speed oil brake rear axle	Tai increase suspension high low speed oil brake rear axle	High low speed rear axle
Battery capacity	72V/200Ah(maintenance free)	72V/130Ah(Water battery)	72V/100Ah(Water battery)	60v/80Ah(Water battery)
Tyre specification	600-14/750-16	450-14/650-16	450-14/600-16	400-12/500-14

About maintenance freight

Since the date of receipt calculation, due to quality problems of the warranty parts, one month round trip freight borne by the store
More than one month in the warranty period by the buyer to bear the freight, non-quality problems and maintenance costs
The return freight is borne by the customer. (We do not accept collected or self-sent packages)
